10.4 inch IR touch frame screen - TopOneTech

10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech

PRODUCT SPECIFICATIONS

Part Numeber(s)

TTS104C2I001

Size

10.4”

Broder(mm)

24

Thickness(mm)

7.9

Touch area(mm)

213*161

Outline dimension

250*198*7.9

Ratio of  length&width

4:3

Glass thick

3mm

Color

Black

MOQ

1 piece

Payment

T/T, Western Union, Credit Card, Paypal, L/C

Delivery time

5-8 working days

Start port

EXW Shenzhen, Guangdong

Certification

FCC, CE, ERP


10.4 inch IR touch frame screen - TopOneTech
10.4 inch IR touch frame screen - TopOneTech
oemtouchmonitor.com/detail/1439.html
998

PRODUCT INTRODUCTION

10.4 inch IR touch frame screen - TopOneTech

A matrix of Infrared(IR)LEDs and photo diodes are used to create a two dimensional grid over the display to detect where infrared light is blocked and thus where touch points are. There is 10.4 inch IR touchscreen which is available in both standard and custom open frame industrial touch display, Toponetech’s projected capacitive touch screens are form, fit or function replacements for 3M™ and Elo™ touch sensors.
